# Usage Guide This guide explains how to run applications that use `/dev/uinput` (like [Sunshine](https://github.com/LizardByte/Sunshine)) inside containers using **`vuinputd`**. You’ll learn how to connect your container to the host’s input proxy, configure permissions, and verify that input devices are visible and functional inside the container. --- ## 1. Overview `vuinputd` allows unmodified apps that use `/dev/uinput` to run safely inside containers. It provides each container with a **virtual `/dev/uinput`**, while a **host-side daemon** mediates all access to the real uinput subsystem. This guide shows how to: 1. Run a container (Docker, systemd-nspawn, or LXC/LXD) 2. Connect it to the host’s virtual `/dev/uinput` 3. Verify that device creation and input forwarding work correctly --- ## 2. Prerequisites Before continuing, ensure the following: * `vuinputd` is **installed and running** on the host → see [docs/BUILD.md](BUILD.md) * You have **root access** on the host (required for mounting and device permissions) * The host kernel supports: * `/dev/uinput` * FUSE/`CUSE` * Optional tools for debugging and validation inside the container: ```bash apt-get install libinput-tools evtest udev tmux ``` --- ## 3. Quick Start (Docker Example) This is the simplest way to verify that `vuinputd` works. ### 🖥️ On the Host 1. Install Docker: ```bash sudo apt-get install docker.io ``` 2. Start a test container with `vuinputd`’s virtual device mapped in: ```bash sudo docker run -it \ --name vuinput-test \ --device=/dev/vuinput:/dev/uinput \ --device-cgroup-rule='c 13:* rw' \ --mount type=bind,src=,dst=/build \ ubuntu:noble ``` *(Replace `` with your actual build directory)* 3. Test the application Just run those lines in the container. ```bash # Allow access for any application chmod 666 /dev/uinput # Prepare udev stubs so applications relying on libudev work mkdir -p /run/udev/data/ touch /run/udev/control # Run the demo application /build/release/mouse-advanced ``` The `vuinputd` daemon on the host should provide some logs. The following section "Verifying Operation" describes a more elaborate check and also some screenshots. 4. Optional: To reuse the container later: ```bash sudo docker start -ia vuinput-test ``` 5. To clean up: ```bash sudo docker rm vuinput-test ``` --- ## 4. Runtime-Specific Setup ### 🐳 Docker (As shown above in Quick Start.) **Key flags:** * `--device=/dev/vuinput:/dev/uinput` — mounts the fake uinput device * `--device-cgroup-rule='c 13:* rw'` — allows access to input devices * Optional: bind your build directory to `/build` for testing binaries --- ### 🧱 systemd-nspawn 1. Install [mkosi](https://github.com/systemd/mkosi): ```bash sudo apt-get install mkosi ``` 2. Create an Ubuntu 24.04 image: ```bash mkosi -d ubuntu -r noble -t directory ubuntu-dir ``` 3. Launch a container with `vuinputd` bound: ```bash /usr/bin/systemd-nspawn \ -M vuinputtest \ -D ubuntu-dir \ --network-veth \ --system-call-filter="@keyring bpf" \ --bind=/proc:/run/proc \ --bind=/sys:/run/sys \ --bind=/dev/vuinput:/dev/uinput \ --bind=/dev/dri \ --property="DeviceAllow=char-drm rw" \ --property="DeviceAllow=char-input rw" \ --property="DeviceAllow=/dev/vuinput rw" \ -b ``` --- ### 🪶 LXC / LXD Add the following to your container configuration: ```ini lxc.cgroup2.devices.allow: c 120:414795 rwm lxc.mount.entry: /dev/vuinput dev/uinput none bind,optional,create=file ``` Then restart the container. *(Adjust the major/minor numbers to match `/dev/vuinput` on your host — check with `ls -l /dev/vuinput`. In the current release, 120:414795 is hardcoded. This may change in the future.)* --- ## 5. Inside the Container Once inside the container shell: ```bash chmod 666 /dev/uinput apt-get update # Optional: install test tools apt-get install libinput-tools udev evtest tmux # Prepare udev stubs mkdir -p /run/udev/data/ touch /run/udev/control ``` --- ## 6. Verifying Operation To test everything, use multiple `tmux` windows for parallel monitoring. 1. Start `libinput` event monitor: ```bash libinput debug-events ``` 2. In another window, observe udev events: ```bash udevadm monitor -p ``` 3. In a third, run: ```bash evtest /dev/input/event* ``` 4. Finally, run the demo binary: ```bash /build/release/mouse-advanced ``` ### Expected Results You should see: * `libinput` reporting device creation and input events * `udevadm` announcing a new `/dev/input/event*` * `evtest` showing input data (e.g. mouse movement) * `journalctl` on the host showing `vuinputd` logs about device creation and event forwarding Sample output from `libinput debug-events`: Sample output from `udevadm monitor -p`: Sample output from `mouse-advanced`: Sample output from `evtest`: Sample output from `journalctl` showing vuinputd output: --- ## 7. Handling Phantom Input Events Caused by VTs On Linux systems without an active graphical session (X11 or Wayland), **virtual terminals (VTs)** remain in text mode (`KD_TEXT`) and continue to process keyboard input via the kernel VT keyboard handler. This can lead to *phantom input events*, where injected or forwarded input (e.g. via `vuinputd`) unintentionally reaches: * `getty` login prompts * inactive consoles * kernel VT hotkeys (e.g. `Ctrl+Alt+Fn`) The following approaches can be used to prevent or mitigate this behavior. ### Solution 1: Use KMSCON (DRM/KMS-based console) A robust solution is to replace the kernel VT text console with a **DRM/KMS-based console** such as `kmscon`. #### How it helps * The kernel VT is no longer responsible for input handling * Keyboard input is processed via evdev, not the VT layer * Seat assignment is respected: * devices on non-default seats (e.g. `seat_vuinput`) are ignored * Phantom input events do not reach `getty` #### Notes * Requires DRM/KMS availability * On most real GPUs, the DRM device remains available even when no monitor is connected and enters a hotplug-waiting state * For headless systems, a virtual KMS device can be used: ```bash modprobe vkms ``` #### Trade-offs * Additional dependencies (DRM, kmscon) * Not always desired for minimal or embedded systems ### Solution 2: VT Guard Mode (`--vt-guard`) `vuinputd` can be started with the `--vt-guard` flag to explicitly neutralize VT input handling. #### How it works At startup, `vuinputd` performs a minimal VT operation such as: * switching the active VT into graphics mode (`KD_GRAPHICS`), or * disabling the kernel keyboard processing for that VT This is done via direct VT ioctls (e.g. `KDSETMODE`), ensuring that: * the kernel VT keyboard handler is inactive * `getty` does not receive injected input events #### Characteristics * Very lightweight * No DRM, compositor, or additional services required * Effective even on fully headless systems #### Caveats * Relies on low-level VT ioctls * Considered **hacky**, but intentionally minimal * Bypasses higher-level session management ### Solution 3: fallbackdm (Work in Progress) `fallbackdm` is an experimental, lightweight **logind-integrated fallback display manager**. #### Intended behavior * Starts only when no graphical session is active * Registers a proper `greeter` session with `systemd-logind` * Takes ownership of a VT and switches it to `KD_GRAPHICS` * Prevents `getty` and the VT keyboard handler from receiving input * Leaves other VTs untouched for emergency local access #### Advantages * Clean integration with `systemd-logind` * No direct VT hacks * Compatible with standard Linux session semantics * Designed to coexist with real display managers #### Status * Currently under development * Intended as the long-term, principled solution ### Summary | Solution | Headless | Lightweight | logind-aware | Recommended for | | ------------ | --------- | ----------- | ------------ | ---------------------------- | | KMSCON | ⚠️ (vkms) | ❌ | ✅ | Full console replacement | | `--vt-guard` | ✅ | ✅ | ❌ | Minimal setups | | fallbackdm | ✅ | ⚠️ | ✅ | Long-term, clean integration | Choose the approach that best fits your system constraints and deployment model. --- ## 8. Troubleshooting | Symptom | Possible Cause | Fix | | --------------------------- | ------------------------------------ | ------------------------------------------------- | | `/dev/uinput` not found | `vuinputd` not running | Start `vuinputd` on host | | Permission denied | Missing `chmod` or wrong cgroup rule | Run `chmod 666 /dev/uinput` or adjust device rule | | No events in container | Missing `/run/udev/control` | Create dummy udev files (see section 5) | | Device appears on host seat | udev rules not isolating | Add udev rules from vuinputd/udev-folder | | Input delayed or missing | CUSE layer error | Check host logs via `journalctl -u vuinputd` | ``` Dez 14 21:33:17 wohnzimmer vuinputd[2172719]: Create /dev/input Dez 14 21:33:17 wohnzimmer vuinputd[2172719]: [2025-12-14T21:33:17Z DEBUG vuinputd::jobs::inject_in_container_job] Error creating input device /dev/input/event12: Read-o> Dez 14 21:33:17 wohnzimmer vuinputd[2172719]: thread '' panicked at vuinputd/src/jobs/inject_in_container_job.rs:161:41: Dez 14 21:33:17 wohnzimmer vuinputd[2172719]: called `Result::unwrap()` on an `Err` value: Os { code: 30, kind: ReadOnlyFilesystem, message: "Read-only file system" } ``` Ensure /dev and /run are writable in the container. If in doubt, use tmpfs. --- ## 9. Notes and Advanced Topics * You can safely run **multiple containers**. * Devices are automatically cleaned up when the container stops. * Works with **Wayland** and **X11** compositors using libinput. * For deeper details, see: * [docs/DESIGN.md](DESIGN.md) * [docs/BUILD.md](BUILD.md) --- ## 10. References * [mkosi manual](https://github.com/systemd/mkosi/blob/main/mkosi/resources/man/mkosi.1.md) * [Docker device rules documentation](https://docs.docker.com/engine/reference/run/#device-cgroup-rule) * [libinput tools](https://wayland.freedesktop.org/libinput/doc/latest/tools.html)
